Roll@Blade
Roll@Blade
Product Summary
● Self-Sharpening Tungsten Rotary Blade: For durability & a sharp cut every time.
● Transparent Clamping Bar: Hold the trimming material in place while allowing you to monitor the trimming process.
● Side Guide & Adjustable Depth Guide: For an easy & precise alignment.
● Trimming Materials: Paper, newsprint, cardboard, plastic films, vellum, aluminum foil, vinyl, pvc, polyester, polypropylene, polyethylene, leather, veneer, etc.
Product Specifications
| Model | Roll@Blade 460 | Roll@Blade 680 | Roll@Blade 920 | Roll@Blade 1600 |
| Item Code | TM460 | TM680 | TM920 | TM1600 |
| Max. Trimming Length | 18”(457mm) | 27”(685mm) | 36”(920mm) | 64”(1600mm) |
| Table Dimensions | 18”x15” | 27”x15” | 36”x15” | 64”x15” |
| Cutting Capacity | 15 sheets (20lbs) | 10 sheets (20lbs) | ||
| Machine Dimensions | 645x485x110mm | 775x485x110mm | 1010x485x110mm | 1690x485x110mm |
| Machine Weight | 5.6kg | 7.4kg | 8.5kg | 14kg |
| Package Dimensions | 775x550x160mm | 1000x550x160mm | 1210x550x160mm | 1940x550x160mm |
| Package Weight | 7.8kg | 9.7kg | 11.2kg | 18.2kg |
| Remark | *Order by MOQ* | *Order by MOQ* | ||
